- 5 -
2-7. Outer dimensions
L-type LN-type LS-type
Z 468
A 181 183 181
B 182 210
C 125
D 165 185 165
D' 200
E 584
a 27
b 35
c 35.5
d 27
Dimension (mm)
D' : With Emergency Stop Device
