English
22
CHANGING THE EXHAUST DIRECTION
WARNING
● When changing the exhaust direction, be sure to remove your
finger from the trigger and disconnect the air hose from the nailer.
The direction of the exhaust vent can be changed by turning the top cover.
USING THE NOSE CAP
WARNING
● When detaching or attaching the nose cap, be sure to remove
your finger from the trigger and disconnect the air hose from the
nailer.
The nose cap is attached to the push lever tip to protect the workpiece from scratches or
damage. Remove in the order shown below when not using.
1 DISCONNECT AIR HOSE FROM NAILER.
2 Pull out the nose cap in the direction of the arrow as shown in the diagram.
䡬 Attach to the tip of the push lever in the reverse order of detaching.
When not using the nose cap, attach to the storage area
in back of the magazine.
Exhaust vent
Top cover
Firing head
Nose cap
Push lever
Nose cap
Disconnect
air hose
1
01Eng_NT50AE2M2_US 10/4/06, 22:0922
