--- 38 ---
Fig. 24
Ratchet Spring [98]
Holder Shaft [95]
Spring Washer M4 [93]
Holder Cap [91]
Nail Holder [99]
Washer M4 [94]
Machine Screw
M5 x 22 [39]
Washer [40]
Gasket (D) [42]
Hex. Socket Hd.
Bolt M5 x 10 [108]
Shingle Guide [107]
Hex. Socket Hd. Bolt
M5 x 14 [106]
Machine Screw
M4 x 50 [92]
Magazine Cover [90]
Hex. Socket Hd. Bolt M5 x 16 [44]
Cap [43]
Sleeve [97]
U-Nut M5 [96]
Body [24]
Plate Nut [104]
Magazine Guard [103]
Pin [101]
Feed Shaft Ring [72]
Guide Base [105]
Nylon Nut M4 [102]
Magazine [100]
U-Nut M5 [96]
