Hitachi P 20SF Service Manual


-5-
• Flatness of base -------------------------------------- Within 0.1 mm (of Front Base [24] and Rear Base [68])
• Parallelism of base ----------------------------------- Within 0.3 mm (as based on Rear Base [68])
Upon completing disassembly and repair, measure the insulation resistance and conduct a dielectric
strength test.
After no-load operation for 30 minutes, the no-load current values should be as follows:
Voltage (V) 110 120 220 230 240
Current (A) max. 2.3 to 3.1 2.2 to 3.0 1.3 to 1.9 1.0 to 1.5 1.0 to 1.5
Product accuracy
Insulation tests
No-load current value

Hitachi P 20SF Specifications

General

Input power	620 W
Power source	AC
Idle speed	17000 RPM
Planning width (max)	82 mm
Chip thickness (max)	2.6 mm
Soft grip	Yes
Product color	Green

Weight and Dimensions

Width	296 mm
Weight	2500 g
