SPECIFICATIONS
NOTE : This specifications are subject to change without notice.
Table 11. Specifications
Item Specification
Product name Liquid crystal projector
Liquid
crystal
panel
Panel size 2.3 cm (0.9 type)
Drive system TFT active matrix
Pixels 480,000 pixels (800 horizontal x 600 vertical)
Lens Zoom lens F=1.7 ~ 2.0 f=37.5 ~ 45.1 mm
Lamp 160 W UHB
Speaker 1.0 W + 1.0W (Stereo)
Power supply AC100 ~ 120V, 2.8A / AC220 ~ 240V, 1.2A
Power consumption 250W
Temperature range 0 ~ 35°C (Operating)
Size 298 (W) x 94.6 (H) x 228 (D) mm
Weight (mass) 3.25 kg
RGB signal
input
RGB IN 1/2
Video: Analog 0.7Vp-p, 75Ω terminator (positive)
H/V. sync.: TTL level (positive/negative)
Composite sync.: TTL level
D-sub 15-pin shrink jack
AUDIO IN
1/2
200mVrms, 50 kΩ (max. 3.0Vp-p)
Stereo mini jack
Video
signal input
VIDEO IN
1.0Vp-p, 75Ω terminator
RCA jack
S-VIDEO IN
Brightness signal: 1.0Vp-p, 75Ω terminator
Color signal: 0.286Vp-p (burst signal), 75Ω terminator
Mini DIN 4-pin jack
AUDIO IN
R/L
200mVrms, 50 kΩ (max. 3.0Vp-p)
RCA jack
Signal
output
RGB OUT
Video: Analog 0.7Vp-p, 75Ω output impedance (positive)
H/V. sync.: TTL level (positive/negative)
Composite sync.: TTL level
D-sub 15-pin shrink jack
AUDIO OUT
200mVrms, output impedance 1 kΩ (max. 3.0Vp-p)
Stereo mini jack
Control
functions
CONTROL D-sub 15-pin shrink plug
USB USB jack (B type)
