English
4
STANDARD ACCESSORIES
○ Sanding paper ..............................................................1
○ Dust bag (for model SV12V, SV12SD) ..........................1
Standard accessories are subject to change without notice.
OPTIONAL ACCESSORIES (sold separately)
1. Sanding paper
○ Perforated sanding paper for model SV12V, SV12SD
○ Non-perforated sanding paper for model SV12SE
○ Grain: AA40, AA60, AA80, AA100, AA120, AA150,
AA180, AA220, AA240
(1) Standard Type (Perforated or non-Perforated), 114 ×
280 mm
(2) Pressure Sensitive Type (Perforated or non-Perforated),
114 × 228 mm
2. Magic Pad (Pressure Sensitive Type), 114 ×
228 mm
(1) Perforated Pad (for model SV12V, SV12SD)
(2) Non-Perforated Pad (for model SV12SE)
3. Cleaner Adaptor (for model SV12V, SV12SD)
4. Punch plate (for model SV12V, SV12SD)
Optional accessories are subject to change without notice.
APPLICATIONS
○ Finish polishing of woodwork surfaces
○ Sanding surfaces of woodwork or sheet metal prior to
painting, etc.
PRIOR TO OPERATION
1. Power source
Ensure that the power source to be utilized conforms
to the power requirements specifi ed on the product
nameplate.
2. Power switch
Ensure that the power switch is in the OFF positon. If the
plug is connected to a receptacle while the power switch
is in the ON position, the power tool will start operating
immediately, which could cause a serious accident.
3. Extension cord
When the work area is removed from the power source,
use an extension cord of suffi cient thickness and rated
capacity. The extension cord should be kept as short as
practicable.
4. Attaching sanding paper
(Start at Switch handle’s side)
(1) Open paper holder by turning the clamping lever
(Fig. 1).
(2) Place the sander as shown in Fig. 2. Insert the sanding
paper between the paper holder and the bottom plate
until it can go no further.
(3) Match the width of the sanding paper with the width of the
pad.
Return the clamping lever to its original position to secure
the sanding paper.
(4) When using perforated sanding paper.
To secure the other end of the sanding paper, pull the
sanding paper while aligning the holes of the sanding
paper with the holes of the pad.
(5) When using non-perforated sanding paper.
Align the sanding paper on the pad and pull the sanding
paper to secure the other end.
CAUTION
(1) After mounting the sanding paper, return the clamping
lever to its original position.
(2) The sanding paper must be precisely attached on the
pad, ensuring that there is ample tension (leaving no
slack). Loosely attached sanding paper could result in
unevenly sanded surfaces and/or damage to the sanding
paper itself.
5. Installing and removing the dust bag. (for models
SV12V and SV12SD)
(1) InstaIIation
As shown in Fig. 4, hold the dust gate and push in the
dust bag into the frame's dust bag holder.
(2) Removal
As shown in Fig. 5, push the dust gate's tab hard and
remove the dust bag from the frame.
PRACTICAL OPERATING PROCEDURES
CAUTION
Never apply water or grinding fl uid when sanding. This
could result in electrical shock.
1. Switching the sander ON and OFF
By pulling the trigger and pushing the stopper, the
switch will remain ON even when the trigger is released,
promoting continuous, effi cient operation. By pulling the
trigger again, the stopper is released and the switch is
turned OFF.
CAUTION
Never turn the power switch ON when the sander is
contacting the surface to be sanded. This is necessary
to preclude damage to the material. The same applies
when switching the power OFF.
SPECIFICATIONS
Model SV12V SV12SD SV12SE
Voltage (by areas)* (110 V, 115 V, 120 V, 127 V, 220 V, 230 V, 240 V)
Power Input 300 W
No-load speed 4000 - 10000/min 10000/min
Diam. of Orbit
2.4 mm
Sanding pad size
114 mm × 228 mm
Sanding paper size 114 mm × 280 mm
Weight (without cord) 2.8 kg 2.8 kg 2.6 kg
* Be sure to check the nameplate on product as it is subject to change by areas.
