9 10
Breath Deflector Removal
1. Push breath deflector flat and pull away from the helmet as arrows indicate.
Breath Deflector Installation
1. Push breath deflector into specified slot as arrows indicate.
Crown Pad Installation
1. Install the front section first by aligning the plastic shell base and the crown pad plastic sleeve, ensuring that the center
and side holes are properly aligned. Press the crown pad plastic sleeve (center portion) into the center of the channel
which is built into the plasticshell base, working your way outward to each side.
2. Align and snap the two rear snaps into place.
Try not to operate the sun visor while riding as this may impair your vision and may lead to an accident.
DO NOT pull on the sun visor when it is already down. The sun visor may be ejected and this will
increase the risk of serious injury or death in the event of an accident.
DO NOT attempt to adjust the sun visor itself with your hands. Always use the sun visor lever.
DO NOT use sun visor at night time. The sun visor is only for day time use. The sun visor does not provide
eye protection. When you use the sun visor be sure that the clear visor is also in closed position
Lever
Above illustration shows raised
sun visor position.
Above illustration shows lowered
sun visor position.
Sun Visor Operation
Lever
Sun Visor Removal
1. While sun visor is in lower position, gently pull it until you see the top of the sun visor.
2. Gently pull one side of the sun visor as arrow indicates (repeat same for other side).
Sun Visor Installation
1. Insert sun visor tab 'A' into 'B' position.(Repeat same on opposite side)
※When installing the sun visor, be sure to have
it slided behind the tap ‘B’ holder.
A
B
Chin Curtain Removal
1. Pull the chin curtain away from the helmet as arrow indicates.
To Next Page
