HJC RPHA 91 User Manual

5 6
1. Feed the chin strap through the opening in the cheek pad.
2. Clip the cheek pad’s 3 small male snaps to the 3 female snaps xed on the shell interior.
3. Install Snap between Cheek pad and neck roll.
Cheek Pad Installation
Cheek Pad Removal
1. Remove Snap between the Cheek pad and neck roll.
2. Gently pry the cheek pad away from the interior, releasing the snaps.
3. Grasp the cheek pad near its center and gently pull it free from the chin strap.
1. Remove Snap between the Cheek pad and neck roll.
2. Pull out the Neck roll to remove.
Neck Roll Removal
1. Assemble the neck roll plastic plate between the shell and the EPS.
2. Install Snap between Cheek pad and neck roll.
Neck Roll Installation
※Slide tab 'A' from the cheek pad into the holder 'B'.
(Repeat same
on opposite side)
3
1
2a
2b
1
1
3
1
2
A
A
B
B

HJC RPHA 91 Specifications

General

Brand	HJC
Model	RPHA 91
Category	Motorcycle Accessories
Language	English
