Page #23 background image
UP00008 ....................................................... $12.99
UP04708 ........................................................ $5.59
ACCESSORY SHEET
LISTE DACCESSOIRES
HOJA DE ACCESORIOS
D06509A .080"(2mm) ........ $3.99
50ft (15m)
STRING REFILL
RECHARGE DE FIL
RECAMBIO PARA LA CUERDA
D06511 .080"(2mm) ;....... $10.99
390ft(118m)
SPOOL RETAINER
ÉCROU DE TAMBOUR
RETEN DEL CARRETE
DA98866A (RH thread) ....... $3.99
SPARK PLUG
BOUGIE
BUJIA
UP03883 (RCJ6Y) .............. $3.59
SPOOL & LINE
TAMBOUR GARNI DE FIL
CARRETE Y CUERDA
UP00145 .080"(2mm) ....... $9.59
No. US $ #
STRING HEAD (RH-Thread)
TÊTE DE COUPE (RH-Thread)
CABEZA DE LA CUERDA (RH-Thread)
STRING REFILL
RECHARGE DE FIL
RECAMBIO PARA LA CUERDA
FUEL CAP
BOUCHON DE RÉSERVOIR
TAPON DE LA GASOLINA
Safety Accessories Accessoires de sécurité Accesorios de seguridad
A06933 GOGGLES ......................................... $4.99
LUNETTES FERMÉES
GAFAS PROTECTORAS
UP07686 EAR PLUGS ( Pkg of 10 ) .................... $9.90
PROTÈGE-OREILLES (trousse de 10 paires)
PROTECTOR AURICULAR (Paquete de conjunto de 10)
UP06835 GLASSES (Clear Lens) .................... $3.99
LUNETTES (verres transparents)
GAFAS (lentes claros)
UP06892 GLASSES (Smoke Lens) ................. $3.99
LUNETTES (verres fumés)
GAFAS (lentes ahumados)
UP06905 GLASSES (Amber Lens) .................. $3.99
LUNETTES (verres ambrées)
GAFAS (lentes ámbar)
DA03001A .080"(2mm)
.....
$18.59
If your Homelite
®
retailer does not have these accessories, you may order direct from PDQ sales in the
continental USA using this form or CALL: 1-800-444-0732
Si votre concessionnaire PDQ ne dispose pas de ces accessoires, vous pouvez les commander directement auprès
de Homelite
®
sur le territoire continental des États-Unis, soit à l'aide de cette page soit PAR TÉLÉPHONE AU
NUMÉRO SUIVANT: 1-800-444-0732
En caso de que su distribuidor de productos PDQ no tenga estos accesorios, usted puede encargarlos directamente
a Homelite
®
en el territorio continental de los Estados Unidos, utilizando el presente formulario, o
LLAMANDO AL NUMERO: 1-800-444-0732
Rev.12/2001
EDGER GUIDE
GUIDE TRANCHE-BORDURES
GUIA DE BORDEAR
Trimmers / Bordures / Cortadoras
Prices subject to change without notice.
Prix sujets à changement sans préavis.
Precios sujetos a cambios sin notificación.
UP00108 ...................................................... $13.99
SHOULDER STRAP
SANGLE
CORREA PARA EL HOMBRO
AIR FILTER
ÉLÉMENT FILTRANT
FILTRO DEL AIRE
UP04270 ........................................................ $3.29
No. US $ #
No. US $ #
No. US $ #
No. US $ #
No. US $ #
No. US $ #
No. US $ #
No. US $ #
No. US $ #
No. US $ #
