Your airbag system includes:
Two SRS (Supplemental Restraint
System) front airbags. The driver’s
airbag is stored in the center of
the steering wheel; the front
passengers’airbagisstoredinthe
dashboard. Both are marked ‘‘SRS
AIRBAG’’ (see page ).
Two side airbags, one for the
driver and one for a front
passenger. The airbags are stored
in the outer edges of the seat-
backs. Both are marked ‘‘SIDE
AIRBAG’’ (see page ).
25
28
CONTINUED
Additional Information About Your Airbags
Airbag System Components
Driver and Passenger Safety
23
(1)
(2)
(3)
(4)
(5)
(4)
(5)
(6)
(8)
(10)
(8)
(7)
(9)
(9)
(7)
(1) Driver’s Front Airbag
(2) Passenger’s Front Airbag
(3) Control Unit
(4) Seat Belt Tensioners
(5) Side Airbags
(6) Driver’s Seat Position Sensor
(7) Front Passenger’s Seat Weight Sensors
(8) Front Impact Sensor
(9) Side Impact Sensors
(10) Passenger Airbag Off Indicator
