Honda 2007 Civic Hybrid User Manual

CONTINUED
Remove the cover, by squeezing
the two tabs and pulling it straight
out.
As shown above, cover the tip of a
flat-tipped screwdriver with a cloth
and move the screwdriver in the
direction of the arrow.
Disconnect the blade assembly
from the wiper arm:
Press and hold the lock tab.
Slidethebladeassemblytoward
the lock tab until it releases
from the wiper arm.
When replacing a wiper blade,
make sure not to drop the wiper
blade or wiper arm down on the
windshield.
2. 3.
Wiper Blades
Maintenance
205
COVER
BLADE ASSEMBLY
TAB
