Open the tailgate. Remove the
light assembly cover by pushing in
the tabs on both sides and pulling
the cover off.
Remove the socket from the light
assembly by turning it one-quarter
turn counterclockwise.
Put the socket back into the light
assembly, and turn it clockwise to
lock it in place.
Pull the bulb straight out of its
socket. Push the new bulb straight
into the socket until it bottoms.
Press the brake pedal to make
sure the new bulb is working.
Put the cover back on the light
assembly. Push it in until it locks
in place.
1.
2.
3.
4.
5.
6.
Lights
Replacing a High-mount Brake
Light Bulb
Maintenance
191
