Lower the wiper arm against the
windshield.
Install the wiper blade assembly
onto the wiper arm. Make sure it
locks in place.
Slide the new blade into the holder.
Make sure it is engaged in the slot
along its full length.
Insert both ends of the blade into
the holder. Make sure they are
secure.
Pull one end of the blade out from
the holder.
Slide the blade out of the holder.
Examine the new wiper blades. If
they have no plastic or metal
reinforcement along the back
edge, remove the metal
reinforcement strips from the old
wiper blade, and install them in
the slots along the edge of the new
blade.
To replace a rear wiper blade:
Raise the wiper arm off the rear
window.
Disconnect the blade assembly
from the wiper arm by pivoting the
blade assembly upward.
3.
5.
4.
6.
7.
1.
2.
Wiper Blades
Maintenance
369
REAR
