Honda CRF250L 2018 User Manual

4. Remove the spark arrester mounting
bolts, spark arrester and gasket from the
muffler.
5.
Use a brush to remove carbon deposits
from the spark arrester screen. Be careful
to avoid damaging the spark arrester
screen. The spark arrester must be free of
breaks and holes. Replace, if necessary.
Check the gasket. Replace, if necessary.
6. Install the gasket and the spark arrester,
and tighten the spark arrester mounting
bolts.
Torque: 6.6 lbf·ft (9.0 N·m, 0.9 kgf·m)
7. Install the tail cap cover and tighten the
tail cap cover bolts.
Torque: 3.9 lbf·ft (5.25 N·m, 0.5 kgf·m)
8. Install the muffler cover and tighten the
muffler cover bolts.
Torque: 1.1 lbf·ft (1.5 N·m, 0.2 kgf·m)
20171129155157_31KZZA500_enu_BOOK Page 64 Wednesday, November 29 2017 16:14:18 JST
Spark Arrester u Cleaning the Spark Arrester
Maintenance
61
Spark arrester screen

Honda CRF250L 2018 Specifications

General

Displacement	249.6cc
Bore x Stroke	76.0mm x 55.0mm
Compression Ratio	10.7:1
Transmission	6-speed
Final Drive	Chain
Front Brake	Single 256mm disc with twin-piston caliper
Rear Brake	Single 220mm disc
Front Tire	3.00-21
Rear Tire	120/80-18
Wheelbase	56.9 inches
Seat Height	34.7 inches
Fuel Capacity	2.1 gallons
Ground Clearance	10.0 inches
Engine Type	Single-cylinder, liquid-cooled, 4-stroke
Fuel System	PGM-FI
Front Suspension	43mm inverted fork
Rear Suspension	Pro-Link single shock
Curb Weight	317 lbs
