Honda CRF250R 2005 User Manual

Vehicle Identification
138 Technical Information
Serial Numbers
The frame, VIN, and engine serial numbers are
required when you register your motorcycle.
They may also be required when ordering
replacement parts. You may record these
numbers in the Quick Reference section at the
rear of the manual.
The VIN (vehicle identification number) (1)
appears on the Safety Certification Label
attached to the left side of the frame.
LEFT SIDE
(1) vehicle identification number
The frame number (2) is stamped on the right
side of the steering head.
RIGHT SIDE
(2) frame number
The engine number (3) is stamped on the left
crankcase.
LEFT SIDE
(3) engine number
(1)
(2)
(3)

Honda CRF250R 2005 Specifications

General

Engine Type	Single-cylinder, four-stroke
Displacement	249 cc
Bore x Stroke	78.0mm x 52.2mm
Compression Ratio	12.5:1
Transmission	5-speed
Valve Train	Unicam, four-valve
Ignition	CDI
Final Drive	Chain
Front Suspension	47 mm inverted Showa cartridge fork with 16-position rebound and 16-position compression damping adjustability; 12.4 inches travel
Front Brake	Single 240 mm disc with twin-piston caliper
Rear Brake	Single 240 mm disc
Front Tire	80/100-21
Rear Tire	100/90-19
Wheelbase	58.3 inches
Fuel Capacity	1.9 gallons
Fuel System	37mm Keihin FCR carburetor
Rear Suspension	Pro-Link Showa single shock with spring preload, 17-position rebound damping adjustability, and compression damping adjustment separated into low-speed (13 positions) and high-speed (3.5 turns); 12.4 inches travel
Curb Weight	204 lbs
