52 Servicing Your Honda
Clutch System
11. Lubricate the O-ring (9), rear brake pedal (10)
pivot and pivot bolt (11) with Honda Lithium
Grease and tighten the pivot bolt to the
specified torque:
27 lbf·ft (37 N·m, 3.8 kgf·m)
Connect the brake pedal return spring (12) if
it was removed.
(9) O-ring (11) pivot bolt
(10) rear brake pedal (12) return spring
12.Fill the crankcase with transmission oil (page
40).
(12)
(10)
(11) (9)

Honda CRF250R 2005 Specifications

General

Engine Type	Single-cylinder, four-stroke
Displacement	249 cc
Bore x Stroke	78.0mm x 52.2mm
Compression Ratio	12.5:1
Transmission	5-speed
Valve Train	Unicam, four-valve
Ignition	CDI
Final Drive	Chain
Front Suspension	47 mm inverted Showa cartridge fork with 16-position rebound and 16-position compression damping adjustability; 12.4 inches travel
Front Brake	Single 240 mm disc with twin-piston caliper
Rear Brake	Single 240 mm disc
Front Tire	80/100-21
Rear Tire	100/90-19
Wheelbase	58.3 inches
Fuel Capacity	1.9 gallons
Fuel System	37mm Keihin FCR carburetor
Rear Suspension	Pro-Link Showa single shock with spring preload, 17-position rebound damping adjustability, and compression damping adjustment separated into low-speed (13 positions) and high-speed (3.5 turns); 12.4 inches travel
Curb Weight	204 lbs
