110 Servicing Your Honda
Suspension
18. Install the disc cover (23) and tighten the disc
cover socket bolts (24) to the specified torque:
10 lbf·ft (13 N·m, 1.3 kgf·m)
19. Turn the rebound damping (25) and
compression damping (26) adjusters back to
their original settings.
(23) disc cover (24) disc cover socket bolts
(25) rebound damping adjuster
(26) compression damping adjuster
(24)
(23)
Left fork:
Right fork:
(26) (25)

Table of Contents

Other manuals for Honda CRF250R

Preview: Owner's Manual & Competition Handbook
Owner's Manual & Competition Handbook168 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Honda CRF250R and is the answer not in the manual?

Honda CRF250R Specifications

General IconGeneral
Engine TypeLiquid-cooled single-cylinder four-stroke
Displacement249cc
Bore x Stroke79.0mm x 50.9mm
Compression Ratio13.9:1
StarterElectric
TransmissionClose-ratio 5-speed
Final DriveChain
Front BrakeSingle 260mm disc with twin-piston caliper
Rear BrakeSingle 240mm disc
Front Tire80/100-21
Rear Tire100/90-19
Wheelbase58.3 inches
Seat Height37.8 inches
Ground Clearance13.1 inches
Fuel Capacity1.7 gallons
Valve TrainUnicam OHC, four-valve
InductionProgrammed Fuel Injection (PGM-FI)
Throttle Bore44mm
IgnitionFull transistorized ignition
Front Suspension49mm inverted Showa coil-spring fork with rebound and compression damping adjustability; 12.2 inches travel
Rear SuspensionPro-Link Showa single shock with adjustable spring preload, rebound and compression damping; 12.4 inches travel
Rake27.2°
Trail115mm (4.5 inches)
