Honda CRF250RX 2022 User Manual

#
Installation
1. Assemble the battery and battery rubber.
u Make sure the + and - marks on the
bottom of the battery rubber align
with the positive + and negative - of
the battery terminals.
2. Install the battery assembly.
3.
Install and tighten the battery terminal
bolts. Always connect the positive +
terminal first. Make sure that bolts and
nuts are tight.
4. Tighten the positive
+
terminal bolt and
negative - terminal bolt to the specified
torque:
Torque: 1.5 lbf·ft (2.0 N·m, 0.2 kgf·m)
5. Install the battery band.
6. Install the battery lid and tighten the bolts
to the specified torque:
Torque: 3.8 lbf·ft (5.2 N·m, 0.5 kgf·m)
For proper handling of the battery, see
“Maintenance Fundamentals.” 2 P. 42
“Battery Goes Dead.” 2 P. 52
Removing & Installing Body Components u Battery
Maintenance
48

Honda CRF250RX 2022 Specifications

General

Displacement	249.4cc
Bore x Stroke	79.0mm x 50.9mm
Compression Ratio	13.9:1
Starter	Electric
Transmission	5-speed
Final Drive	Chain
Front Brake	Single 260mm disc with twin-piston caliper
Rear Brake	Single 240mm disc
Front Tire	80/100-21
Rear Tire	110/100-18
Wheelbase	58.3 inches
Seat Height	37.8 inches
Fuel Capacity	2.1 gallons
Engine Type	Single-cylinder four-stroke
Valve Train	DOHC; four valves
Induction	PGM-FI
Ignition	Full transistorized
Front Suspension	49mm inverted Showa fork with rebound and compression damping adjustability, 12.2 inches travel
Rear Suspension	Pro-Link Showa single shock with adjustable spring preload, rebound and compression damping; 12.3 inches of travel
