Honda CRF250X 2006 User Manual

Fuel System
Fuel Filter
The fuel filter is mounted on the bottom left side
of the fuel tank. Dirt accumulated in the filter
will restrict the flow of the fuel to the carburetor.
To service the fuel filter:
1. Drain the fuel from the fuel tank into an
approved gasoline container.
2. Remove the fuel tank (page 37).
3. Remove the fuel filter (1) from fuel tank by
removing the bolts (2). Wash the fuel filter in
high flash-point cleaning solvent.
4. Reassemble the fuel filter in the reverse order
of removal. Make sure the O-ring (3) is in
place. Install the fuel filter in the fuel tank.
Refill the fuel tank.
Attach the fuel valve and fuel line, and turn
the fuel valve to ON or RES; check for leaks.
(1) fuel filter (3) O-ring
(2) bolts
(2)
(3)
(1)
42 Servicing Your Honda

Honda CRF250X 2006 Specifications

General

Engine Type	Liquid-cooled single-cylinder four-stroke
Displacement	249 cc
Valve Train	Unicam, four-valve
Induction	Keihin 37 mm flat-slide carburetor
Transmission	5-speed
Front Brake	Single 240 mm disc with twin-piston caliper
Rear Brake	Single 240 mm disc
Front Tire	80/100-21
Rear Tire	100/100-18
Wheelbase	58.3 inches
Ground Clearance	13.6 inches
Bore x Stroke	78.0mm x 52.2mm
Final Drive	Chain
Front Suspension	47 mm inverted Showa cartridge fork with 16-position rebound damping adjustability; 12.4 inches travel
Rear Suspension	Pro-Link Showa single shock with spring preload, 17-position rebound damping adjustability, and compression damping adjustment separated into low-speed (13 positions) and high-speed (3.5 turns); 12.4 inches travel
