Honda CRF450R 2017 User Manual

Instruments & Controls 9
MIL (Malfunction Indicator Lamp)
Refer to MIL Blink Pattern on page 7.
Should be serviced by your dealer, unless the owner has proper tools and is technically qualified.
The series of 12 MIL blinks cannot be checked because the engine cannot be started.
If the engine does not start, check all connector connections and/or refer to an official Honda Service
Manual (page 160) for troubleshooting of the PGM-FI symptom.
DTC Index
MIL blinks Function Failure Symptom/Fail-safe function
1 MAP sensor circuit malfunction Poor performance (driveability)
2 MAP sensor performance problem Poor performance (driveability)
7 ECT sensor circuit malfunction Hard start at a low temperature
8 TP sensor circuit malfunction Poor engine acceleration
9 IAT sensor circuit malfunction Engine operates normally
12 Injector circuit malfunction
• Engine does not start
• Injector, fuel pump and ignition shut down
0.(ERRN࣮࣌ࢪ㸰㸮㸯㸴ᖺ㸷᭶㸯᪥ࠉᮌ᭙᪥ࠉ༗ᚋ㸰󰪍㸳㸴ศ

Honda CRF450R 2017 Specifications

General

Engine Type	449cc liquid-cooled single-cylinder four-stroke
Bore x Stroke	96.0mm x 62.1mm
Compression Ratio	13.5:1
Induction	Programmed Fuel Injection (PGM-FI), 46mm throttle body
Transmission	Close-ratio five-speed
Final Drive	#520 Chain; 13T/49T
Rear Suspension	Pro-Link Showa single shock with spring preload, rebound and compression damping adjustability; 12.4 inches travel
Front Brake	Single 260mm disc with twin-piston caliper
Rear Brake	Single 240mm disc
Front Tire	80/100-21
Rear Tire	120/80-19
Trail	116mm (4.6 inches)
Wheelbase	58.3 inches
Seat Height	37.8 inches
Valve Train	Unicam, 4-valve
Ignition	Full transistorized
Curb Weight	243 pounds
