Honda CRF450R 2023 User Manual

#
Installation
1. Assemble the battery and battery rubber.
u Make sure the + and - marks on the
bottom of the battery rubber align
with the positive + and negative - of
the battery terminals.
2. Install the battery assembly.
3. Install and tighten the battery terminal
bolts. Always connect the positive +
terminal first. Make sure that bolts and
nuts are tight.
4. Tighten the positive + terminal bolt and
negative - terminal bolt to the specified
torque:
Torque: 2 N·m (0.2 kgf·m, 1.5 lbf·ft)
5. Install the battery band.
6. Install the battery lid and tighten the bolts
to the specified torque:
Torque: 5.2 N·m (0.5 kgf·m, 3.8 lbf·ft)
For proper handling of the battery, see
“Maintenance Fundamentals.” 2 P. 47
“Battery Goes Dead.” 2 P. 57
20230714150511_42MKE6210_eng_BOOK Page 60 Friday, July 14 2023 15:07:32 JST
Removing & Installing Body Components u Battery
Maintenance
53

Honda CRF450R 2023 Specifications

General

Bore x Stroke	96.0mm x 62.1mm
Compression Ratio	13.5:1
Ignition	Full transistorized
Transmission	5-speed
Final Drive	#520 Chain; 13T/49T
Front Brake	Single 260mm disc with twin-piston caliper
Rear Brake	Single 240mm disc
Front Tire	80/100-21
Rear Tire	120/80-19
Wheelbase	58.3 inches
Seat Height	37.8 inches
Curb Weight	245 pounds
Fuel Capacity	1.7 gallons
Ground Clearance	13.2 inches
Engine Type	Single-cylinder four-stroke
Induction	Programmed Fuel Injection (PGM-FI)
Front Suspension	49mm inverted Showa fork with rebound and compression damping adjustability; 12.2 inches of travel
Rear Suspension	Pro-Link Showa single shock with rebound and compression damping adjustability; 12.4 inches of travel
