Honda EU2000i User Manual

72
TECHNICAL INFORMATION
Specifications
Dimensions
Engine
Generator
Tuneup Specifications
Specifications are subject to change without notice.
Model EU2000i
Description code EACT
Length 20.2 in (512 mm)
Width 11.4 in (290 mm)
Height 16.7 in (425 mm)
Dry mass [weight] 45.6 lbs (20.7 kg)
Model GX100
Engine type 4-stroke, overhead camshaft, single cylinder
Displacement
[Bore×Stroke]
6.01 cu-in (98.5 cm
3
)
[2.20×1.57 in (56.0×40.0 mm)]
Compression ratio 8.5:1
Engine speed 4,300–5,000 rpm
(with Eco-Throttle switch OFF)
Cooling system Forced air
Ignition system Full transistor
Engine oil capacity 13 oz (0.40 L)
Fuel tank capacity 0.95 US gal (3.6 L)
Spark plug CR5HSB (NGK)
Model EU2000i
Type A1 type
AC output
Rated voltage 120 V
Rated frequency 60 Hz
Rated current 13.3 A
Rated output 1.6 kVA
Maximum output 2.0 kVA
DC output Only for charging 12 V automotive batteries.
Maximum changing output = 8 A
ITEM SPECIFICATION MAINTENANCE
Spark plug gap
0.024 – 0.028 in (0.6 – 0.7 mm) Refer to page 53.
Valve clearance
(cold)
IN: 0.15±0.04 mm
EX: 0.20±0.04 mm
See your authorized
Honda dealer.
Other specifications No other adjustments needed.
31Z39600.book 72 ページ ２０１３年４月１０日 水曜日 午前１０時３４分

Honda EU2000i Specifications

General

Model	EU2000i
Type	Inverter
AC Output	120V
Engine	Honda GX100
Displacement	98.5cc
Run Time at Rated Load	3.4 hours
Run Time at 1/4 Load	8.1 hours
Starting System	Recoil
Dry Weight	45.6 lbs
Maximum AC Output	2000W
Rated AC Output	1600W
DC Output	12V, 8A
Engine Type	4-stroke, OHV, single cylinder
Fuel Tank Capacity	0.95 gallons
Run Time per Tankful	3.4 hrs @ rated load, 8.1 hrs @ 1/4 load
Noise Level	53 to 59 dBA
Dimensions	20.1" x 11.4" x 16.7"
