General| Engine Type | Air-cooled 4-stroke OHV |
|---|---|
| Compression Ratio | 8.5:1 |
| PTO Shaft Rotation | Counterclockwise (from PTO shaft side) |
| Ignition System | Transistorized magneto ignition |
| Starting System | Recoil starter |
| Air Cleaner | Dual element |
| Fuel System | Carburetor |
| Lubrication System | Splash |
| Displacement | 163 cm³ |
| Bore x Stroke | 68 mm x 44 mm |
| Net Power Output | 4.8 HP (3.6 kW) at 3, 600 rpm |
| Net Torque | 10.3 Nm (7.6 lb ft) @ 2, 500 rpm |
| Fuel Tank Capacity | 3.1 L (0.82 US gal) |
| Fuel Consumption | 1.4 L/h at 3, 600 rpm |
| Oil Capacity | 0.6 liters |
| Dry Weight | 15.1 kg |
