ENGLISH 5
3. Turn the engine switch to the ON position.
4. Pull the starter grip lightly until you feel resistance, then pull briskly in
the direction of the arrow as shown below. Return the starter grip
gently.
Do not allow the starter grip to snap back against the engine.
Return it gently to prevent damage to the starter.
5. If the choke lever was moved to the CLOSED position to start the
engine, gradually move it to the OPEN position as the engine warms
up.
SETTING ENGINE SPEED
Position the throttle lever for the desired engine speed.
Some engine applications use a remote-mounted throttle control rather
than the engine-mounted throttle lever shown here.
For engine speed recommendations, refer to the instructions provided
with the equipment powered by this engine.
ENGINE SWITCH
ON
ON
(EQUIPMENT SIDE)
STARTER GRIP
Direction to pull
CHOKE LEVER
OPEN
OPEN
MIN.
THROTTLE LEVER
MAX.
MIN.
MAX.
37ZDD6020.fm 5 ページ ２０１９年１１月１９日 火曜日 午前９時３分

Honda GX100 Specifications

General

Bore x Stroke	56 mm x 40 mm
Compression Ratio	8.5:1
PTO Shaft Rotation	Counterclockwise (from PTO shaft side)
Ignition System	Transistorized magneto ignition
Starting System	Recoil starter
Lubrication System	Forced splash
Engine Type	4-stroke
Displacement	98 cm3
