Honda GX22 User Manual

36
SERVICING YOUR HONDA ENGINE
SPARK ARRESTER SERVICE
SPARK ARRESTER SCREEN
DEFLECTOR GUARD
4 mm SCREWS
DEFLECTOR
SPARK ARRESTER
TOP COVER
The spark arrester must be serviced every 100 hours to keep it
functioning as designed.
If the engine has been running, the muffler will be very hot. Allow the
muffler to cool before servicing the spark arrester.
To reach the spark arrester screen on vertical-shaft engines, remove
the deflector guard from the engine top cover and the deflector from
the spark arrester by removing the 4 mm screws as shown below for
reaching the spark arrester screen.
Use a brush to remove carbon deposits from the spark arrester
screen. Be careful to avoid damaging the screen.
The spark arrester must be free of breaks and holes. Replace the
spark arrester if it is damaged.
01/04/03 12:10:57 31ZM3601_037

Honda GX22 Specifications

General

Compression Ratio	8.0:1
PTO Shaft Rotation	Counterclockwise (from PTO shaft side)
Ignition System	Transistorized magneto
Starting System	Recoil Starter
Air Cleaner	Semi-dry type
Lubrication System	Forced splash
Engine Type	4-stroke
Oil Capacity	0.08 liters
