SERVICING YOUR TRIMMER
31
5. When you have about 6 inches (150 mm) of
line remaining, press the lines into the two
notches on the bottom of the spool. This will
hold the lines on the spool for reassembly.
6. Feed both line ends through the metal eyelets
in the housing.
Be careful not to let the line slip under the
spool. When the spool reaches the bottom of
the housing, the lines should snap out of the
spool notches.
If you are not sure the lines have snapped out
of the notches, gently pull the spool away
from the housing about an 1/8 inch to inspect
the lines. If necessary, gently pull each line
until you hear it snap out of the notch. Trim
the lines so they are equal length.
7. Install the spring and knob. Rotate the knob in
the direction of the arrow and hand tighten
securely.
NOTCHES
METAL
EYELETS (2)
