17
Specifications
Mower Features
Dimensions and Weights
Engine Design and Performance
Maintenance
HRR2169PKUA Honda rotary mower, 530mm mower deck,
Clip Director, flywheel brake, Auto Choke
System
Length 1534mm
Width 582mm
Overall height * 1014mm
Dry weight 33.8kg
Cutting width 530mm
Cutting heights (7) 28 ~ 102mm
Grass bag
capacity
66L
Noise level < 75 dB(A) @ 7.5(m) LpA
* 1-1/4 inch cutting height and handle in highest position
Model GCV160
Type 4-stroke, overhead-cam,
single-cylinder, air-cooled
Displacement
160cm
3
Bore and stroke 64 x 50mm
Compression ratio 8.5:1
Ignition system Transistorized magneto
Fuel Unleaded petrol with a pump
octane rating of 86 or higher containing
no more than 10% ethanol by volume
Capacity: 0.93 litres
See “AVOIDING FUEL-RELATED
PROBLEMS” on page 18
page 7
Blade Bolt
Torque
49 ~ 59N•m page 11
Engine Oil SAE 10W-30, API SJ or later
Capacity: 0.50 litres
Refill amount: 0.35 ~ 0.40 litres*
page 12
Spark Plug Type: NGK - BPR5ES
Gap: 0.7 ~ 0.8mm
page 13
Maximum
Governed
Speed
3,100 +0/-150rpm ** Shop
manual
Valve
clearance
(cold)
Intake: 0.15 ± 0.04mm
Exhaust: 0.20 ± 0.04mm
Shop
manual
* Actual amount will vary due to residual oil in the engine. Always
use the dipstick to confirm the actual level (page 6).
**Do not try to increase the engine speed above the maximum
governed speed; the blades could fracture and come apart.
