AIR INDEX
An Air Index Information hang tag/label is applied to engines certified
to an emission durability time period in accordance with the
requirements of the California Air Resources Board.
The bar graph is intended to provide you, our customer, the ability to
compare the emissions performance of available engines. The lower
the Air Index, the less pollution.
The durability description is intended to provide you with information
relating the engine’s emission durability period. The descriptive term
indicates the useful life period for the engine’s emission control
system. See your EMISSION CONTROL SYSTEM WARRANTY
(page 20
) for additional information.
SPECIFICATIONS
Mower Model
Maintenance
Tuneup
Dimensions, Weights, and Capacities
Engine Design and Performance
Transmission Design and Performance
Descriptive Term Applicable to Emissions
Durability Period
Moderate 50 hours (0 ~ 80 cc)
125 hours (greater than 80 cc)
Intermediate 125 hours (0 ~ 80 cc)
250 hours (greater than 80 cc)
Extended 300 hours (0 ~ 80 cc)
500 hours (greater than 80 cc)
1000 hours (225 cc and greater)
HRX217K2VKA Honda rotary mower, grass bag, 21-inch
mower deck, Clip Director, variable speed
transmission, flywheel brake, fully
automatic choke
Fuel Unleaded gasoline with a pump
octane rating of 86 or higher.
page 13
Engine oil SAE 10W-30, API SJ or later page 11
Spark plug type NGK BPR5ES page 12
Maximum governed
speed
* 2,950 ~ 3,100 rpm Shop
manual
Blade bolt torque 36 ~ 43 ft-lb (49 ~ 59 N•m) page 10
* Do not try to increase the engine speed above the maximum
governed speed; the blades could fracture and come apart.
Spark plug gap 0.028 ~ 0.031 in
(0.7 ~ 0.8 mm)
page 12
Valve clearance
(cold)
Intake:0.15 ± 0.04 mm
Exhaust:0.20 ± 0.04 mm
Shop
manual
Other specifications No other adjustments needed.
Overall length 63.8 in (1621 mm)
Width at mower deck 23 in (585 mm)
Overall height 38.4 in (976 mm)
Dry weight 88.6 lb (40.2 kg)
Wheelbase [cutting
height adjusters set to
1-1/4 in (32 mm)]
26.7 in (678 mm)
Cutting width 21 in (530 mm)
Approximate cutting
height (7 adjustable
positions)
3/4, 1-1/4, 2, 2-1/2, 3, 3-1/2, 4 in
(20, 32, 46, 62, 75, 88, 100 mm)
Fuel tank capacity 0.25 US gal (0.93 l)
Engine oil capacity 18.6 oz (0.55 l)
** Refill amount: 12.0 ~ 13.5 oz
(0.35 ~ 0.40 l)
Grass bag capacity 23 US gal (2.5 bushels; 3.1 cu ft; 88 l)
** Actual amount will vary based on residual oil in the engine.
Always use the dipstick to confirm the actual level (see page 11
).
Engine model GCV190
Engine type 4-stroke, overhead-cam, single-cylinder,
forced air-cooled
Displacement 11.4 cu in (187 cc)
Bore and stroke 2.71 x 1.97 in (69 x 50 mm)
Compression ratio 8.5:1
Ignition system Transistorized magneto
Transmission type Variable speed, thumb or hand operation
(twist grip) Smart Drive
Mower ground speed
(engine at 3,100 rpm)
0 ~ 3.6 mph (0 ~ 1.6 m/s)
