544
uuMaintenance Under the BonnetuOpening the Bonnet
Opening the Bonnet
1. Park the vehicle on a level surface, and set
the parking brake.
2. Pull the bonnet release handle under the
driver’s side lower outside corner of the
dashboard.
u The bonnet will pop up slightly.
3. Push the bonnet latch lever (located under
the front edge of the bonnet to the centre)
to the side and raise the bonnet. Once you
have raised the bonnet slightly, you can
release the lever.
Do not open the bonnet when the wiper arms are
raised. The bonnet will strike the wipers, resulting in
possible damage to the bonnet and/or the wipers.
When closing the bonnet, check that the bonnet is
securely latched.
If the bonnet latch lever moves stiffly, or if you can
open the bonnet without lifting the lever, the latch
mechanism should be cleaned and lubricated.
a Bonnet Release Handle
b Pull
21 JAZZ HYBRID SSS-32TZA6000.book 544 ページ ２０２０年１月２９日 水曜日 午前１０時３２分
