Blown Fuse
Before handling fuses, see “Inspecting and
Replacing Fuses.” 2 P. 78
#
Fuse Box Fuses
1.
Remove the battery lid. 2 P. 87
2.
Remove the fuse box cover.
3.
Pull the main fuse A, main fuse B and
other fuses out one by one with the fuse
puller furnished in reverse side of the fuse
box cover and check for a blown fuse.
Always replace a blown fuse with a spare
fuse of the same rating.
4.
Reinstall the fuse box cover.
5.
Install the battery lid.
NOTICE
If a fuse fails repeatedly, you likely have an
electrical problem. Have your scooter inspected
by your dealer.
20180803173345_32K40L220_eng_BOOK Page 128 Friday, August 03 2018 17:38:27 JST
Electrical Trouble u Blown Fuse
Troubleshooting
125
Fuse box
cover
Fuse puller
Spare fuses
Main fuse A Main fuse B
To Next Page
