General| Engine Type | 644cc air-cooled dry-sump single-cylinder four-stroke |
|---|---|
| Bore x Stroke | 100.0mm x 82.0mm |
| Compression Ratio | 8.3:1 |
| Ignition | CD with electronic advance |
| Transmission | 5-speed |
| Front Tire | 3.00-21 |
| Rear Tire | 4.60-18 |
| Rake | 28.0 degrees |
| Wheelbase | 57.3 inches |
| Seat Height | 37.0 inches |
| Fuel Capacity | 2.8 gallons |
| Ground Clearance | 13.0 inches |
| Induction | 42.5mm diaphragm-type CV carburetor |
| Front Suspension | 43mm telescopic fork; 11.6 inches travel |
| Rear Suspension | Pro-Link single-shock; fully adjustable; 11.0 inches travel |
| Front Brake | Single disc |
| Curb Weight | 346 pounds (Includes all standard equipment, required fluids and full tank of fuel-ready to ride) |
| Rear Brake | Single disc with single-piston caliper |
