F111 (SERIES 11000) IN CEILING MEDIA AIR CLEANER
68-0198EF-2 8
PARTS LIST
Refer to Fig. 8 and Table 4 for replacement part information.
Table 4. Replacement Parts.
Fig.
Reference No. Description Pack Qty Order Number Reference No.
1 CPZ™ sorbent module (requires 2)—used with only
95% HEPA or 95% ASHRAE particle filters
1 32004078-001 31005
2 Blower wheel 1 32002285 810103
3 Motor capacitor; 120V, 60 Hz 1 32000265 810183
Motor capacitor; 208/230V, 50/60 Hz 1 32000549 810157
Motor capacitor; 277V, 60 Hz 1 32000550 810160
4 Motor; 120 V, 60 Hz 1 32000270 810208
Motor; 208/230V, 50/60 Hz 1 32000263 810158
Motor; 277V, 60 Hz 1 32000264 810159
5 99.97% HEPA media filter 1 32000204 21002
95% hospital grade filter 1 32000203 21001
6 Prefilter (disposable) 1 32002307 810134
7 Lid assembly without hinges and latches 1 32002308 810198
OPTIONAL Parts not shown in Fig. 8.
Speed switch, variable 1 32000234 41105
Grounded 8 ft power cord 1 32000235 41107
Motor mount bracket 1 32000260 810143
Motor maintenance grommet set 3 32000261 810144
Snap-loc Tabs 1 32000262 810151
Z Sidemount Bracket Kit 4 32002353 —
Series 1 to Series 2 Upgrade Kit 1 32002287 —
Spring Loaded Plunger 2 32002278 —
