Operation and maintenance manual HON HSV086 4
1 Technical Specifications
1.1 General
Type : HON HSV086 / HON HSVS086
Nominal diameter : 1” – 20”
Pressure categories : ANSI 300 and 600 under EN certification
: ANSI 900 and 1500 just PED certification
Design : PED, EN 14382, EN 12516, EN 13445, ANSI B16.10
Operating pressure : up to 250 bar
Threshold value:
against high pressure : 1.23 to 49.5 bar ANSI 300 / 1.23 to 95 bar ANSI 600
60 to 130 bar ANSI 900/1500
against low pressure : 0 up to 15 bar
Reproducibility
high pressure : AG 1 between 20 - 95 bar
: AG 2.5 between 1.23 – 17 bar
low pressure : AG 10 between 0 - 15 bar
Temperature range : -20 up to +60°C,
Closing time : < 1 sec.
Building-in position : horizontally with switch and reset mechanism up
PIN-DVGW No. HON HSV(S) : CE-0085BS0202
1.2 Materials
Valve body / Cover : A352 Gr.LCC, A350, S355NL, P355N or equal
Valve rod : X17CrNi16-2
Guides : X17CrNi 16-2 + QT800 or X2CrNiMoN 22-5-3
Valve stem : C35 or equivalent
O-rings : Viton and NBR or equivalent
Diaphragm : NBR with nylon
SVC086 (operational parts) : stainless steel
Dual tripping device : brass and steel
When corrosive gasses are used, other materials may be necessary. We would advise always to
describe the composition of the gas exactly when placing the order.
