17
To Assemble:
1) Work the lens seal onto the facepiece, making sure that it is centered and there are no gaps.
2) Work the upper and lower lens clamps onto the lens and face seal.
3) Use the needle-nose pliers to bring the two lens clamps together. Insert the screws so the thread side faces up.
4) Seat the nut into the cavity of the lens clamp and thread the nut onto the screw and tighten.
CAUTIONS
STORAGE
Store in a clean, dry area away from the chance of any contamination. Use the respirator storage bag provided with the facepiece
or any other sealable container that will protect the facepiece. Optimum storage conditions are room temperature, between
50°F (10°C) and 100°F (38°C).
WARNING
Do not use abrasive cleaners on the lens. Abrasives can remove the protective coating from the lens, making it susceptible to
scratch and chemical degradation.
Never store the facepiece with cartridges or filters that have been exposed to contaminants. If cartridges and/or filters are
to be reused, seal them in a separate bag or container. Do not expose to direct sunlight, chemical pollutants or dust.
Cartridges that have been exposed to contaminants with a low boiling point, and all NIOSH rated R filters that have been
exposed to oil-based aerosols must be discarded at the end of a shift.
Failure to comply with these warnings will result in the risk of serious injury, illness or death.
