Page #4 background imageLoading...
Page #4 background image
SPYDER® BACNET® PROGRAMMABLE CONTROLLERS
63-1328—05 4
Universal Input (UI) Circuits
See Table 2 for the UI specifications:
Hardware (PUB6438S, PUB6438SR,
PVB6436AS, and PVB6438NS)
CPU
Each controller uses a pair of microprocessors. The first is a
16-bit Texas Instruments MSP430 family microprocessor that
is used to manage the Inputs, Outputs and Control. The
second is a 32-bit ATMEL ARM 7 microprocessor that
manages communication for the Spyder BACnet.
Memory Capacity
Flash Memory: 372 kilobytes. The controller is able to retain
Flash memory settings for up to ten (10) years.
RAM: 72 kilobytes
Hardware (PVB0000AS, PUB1012S,
PUB4024S, PVB4022AS, and
PVB4024NS)
CPU
Each controller uses a 32 bit ATMEL ARM 7 microprocessor.
Memory Capacity
Flash Memory: 512 kilobytes. The controller is able to retain
Flash memory settings for up to ten (10) years.
RAM: 128 kilobytes
Controller Status LED
The LED on the front of the controller provides a visual
indication of the status of the device. When the controller
receives power, the LED appears in one of the following
allowable states, as described in Table 3.
BACNET STATUS LED:
The LED on the front of the controller, between the BACnet
MS/TP terminals and MAC Address DIP Switches, provides a
visual indication of the BACnet MS/TP communication status.
When the controller receives power, the LED appears in one
of the following allowable states, as described in Table 4.
Table 2. Universal Input Circuit Specifications.
Input
Type
Sensor
Type
Operating
Range
Room/Zone
Discharge Air
Outdoor Air
Temperature
20K Ohm
NTC
-40° F to 199° F
(-40° C to 93° C)
Outdoor Air
Temperature
C7031G
a
a
C7031G and C7041F are recommended for use with these
controllers, due to improved resolution and accuracy when
compared to the PT1000.
b
One Universal Input (UI-1*) on the PUB1012S, PUB4024S,
PVB4022AS, and PVB4024NS is user selectable as a fast
digital pulse meter.
-40° to 120°F
(-40° to 49°C)
C7041F
a
-40° to 250°F
(-40° to 121°C)
PT1000
(IEC751 3850)
-40° F to 199° F
(-40° C to 93° C)
TR23
Setpoint
Potentiometer
500 Ohm
to
10,500 Ohm
-4° DDC to 4° DDC
(-8° DDF to 7° DDF)
or
50° F to 90° F
(10° C to 32° C)
Resistive Input Generic 100 Ohms
to
100K Ohms
Voltage
Input
Transducer,
Controller
0 - 10 Vdc
Discrete Input Dry Contact
closure
OpenCircuit 3000Ohms
ClosedCircuit < 3000Ohms
Pulse Input
b
Counter/Meter Max. frequency: 15 Hz
Min. pulse width: 20 ms
Table 3. Status LED States.
LED State Blink Rate Status or Condition
OFF not applicable No power to processor,
LED damaged, low voltage
to board, first second of
power up, or loader
damaged.
ON ON steady;
not blinking
Processor not operating.
Application Program CRC
being checked. This takes
1-2 seconds and occurs on
each restart (power up,
reset and reflash, and
following configuration file
download).
Very Slow
Blink
(continuous)
1 second ON,
1 second OFF
Controller is operating
normally.
Slow Blink
(continuous)
0.5 second ON,
0.5 second OFF
Controller alarm is active
or controller in process of
configuration file
download.
Medium Blink
(continuous)
0.3 second ON,
0.3 second OFF
Controller is in reflash
mode or awaiting/receiving
reflash data via the
BACnet network.
