Hoonved CAP 10 E BT User Manual

38
ENGLISH
Part 3: For the technician
STANDARD SETTING PARAMETERS "P"
IMPORTANT
With P1=1: filling and heating of water in the tank is
carried out alternately, with pre-heated water from the
boiler, until the water level in the tank is reached.
*With P3=1: check fuse value of the safety
upstream of the machine (A).
3.2.b Altering PARAMETERS “T” and “L”
Press START “ST” to view programmed temperature.
The message “t1” will appear on the display,
indicating the temperature set for the water in the
tank (for the selected cycle).
Now press the “SD” or CYCLE button to decrease and/
or the “SI” button to increase the temperature/time
settings.
(See table STANDARD SETTINGS PARAMETERS
“T” and “L”)
To confirm parameters and move on to the
following settings (in sequence L1 - L2 - L3 - L4 -
L5) press the “ST” button again.
To exit settings, simply refrain from pressing any
buttons for at least 10 sec.
3.2.a Altering PARAMETERS “P”
From within “Pro” settings, press the START “ST”
button; the message “P1” will be displayed
To confirm parameters in sequence “P” (P1 - P2 - P3 -
P4) press the “ST” button.
Now press the “SD” or CYCLE button to decrease and/or
the “SI” button to increase the parameter status (0-1).
(See table STANDARD SETTINGS PARAMETERS “P”)
To exit settings, simply refrain from pressing any
buttons for at least 10 sec.
*
STANDARD SETTING PARAMETERS "T" and "L"
DYSPLAY ALARMS and
SIGNALS : SELF-DIAGNOSIS
when more than one alarm is detected simultaneously,
the relative codes will appear on the display in the
following order of priority:
1. H1-H2-H3
2. A1-A2-A3-A4-A5
3. F1-F2
The alarm and active function codes shown on the
display when the machine is in operation are:
- A1: FAILURE TO COMPLETE CYCLE
This alarm message appears when the machine
is switched back on after being switched off
using “IL”.
- A2 : BOILER OVERHEATING
This alarm message appears when the temperature
in the boiler exceeds 105°C;
(the cycle underway will be completed).
3.2.c STANDARD Parameter Settings
With the machine switched off, press the “SI” button for
10 sec.; all parameters (P-T-L) are automatically set
as in the tables.
The message “PSt” will appear on the display,
confirming that the settings have been
programmed.
.
PARAMETER FUNCTION SHORT MEDIUM LONG INTENSIVE
CYCLE CYCLE CYCLE CYCLE
LC1 LC2 LC3 LC4
T1 Tank temperature 55°C 55°C 55°C 55°C
T2 Boiler entry temperat. 85°C 85°C 85°C 85°C
L1 Wash time 42 sec. 77 sec. 127 sec. 457 sec.
L2 Pause time 5 sec. 5 sec. 5 sec. 5 sec.
L3 Rinse time 18 sec. 18 sec. 18 sec. 18 sec.
L4 - - - - -
L5 - - - - -
PARAMETER FUNCTION SHORT MEDIUM LONG INTENSIVE
CYCLE CYCLE CYCLE CYCLE
LC1 LC2 LC3 LC4
T1 Tank temperature 55°C 55°C 55°C 55°C
T2 Boiler entry temperat. 85°C 85°C 85°C 85°C
L1 Wash time 42 sec. 77 sec. 127 sec. 457 sec.
L2 Pause time 5 sec. 5 sec. 5 sec. 5 sec.
L3 Rinse time 18 sec. 18 sec. 18 sec. 18 sec.
L4 - - - - -
L5 - - - - -
LC1
LC2 LC3
LC4
CAP 10-SO 100E
CAP 12-SO 120E
PARAMETER FUNCTION 0 FUNCTION 1 PRESET
STATUS
P1 Filling hot water Filling cold water 0
(40÷50°C)
P2 Normal washing with Pre-rinse 0
P3 Alternating heating Simultaneous 0
(first boiler than tank) heating (tank & boiler)
P4 1 wash pump Not used 0
P5 Wait for boiler to heat Wait for boiler to heat 1
NOT ACTIVE ACTIVE
P6 Cycle START tank temp. Cycle START tank temp. 0
reached (preset) reached (preset)
NOT ACTIVE ACTIVE
P7 Not used 0
