Hoover H-WASH 300 LITE User Manual

!
6
2. INSTALLATION
! Remove the 2 or 4 transportation
screws (A) on the back and
remove the 2 or 4 flat washers,
rubber bungs and plastic spacer
tubes (B) as illustrated in figure 1.
! If the washing machine is built-in,
unscrew the 3 or 4 transportation
screws (A) and remove the 3 or 4
flat washers, rubber bungs and
plastic spacer tubes (B).
! During the removal of the screws
occasionally spacer tubes fall
inside the product, these can be
remove by tilting the product forward
and recovering them from the floor or
inside the base of the machine.
! Cover the open transportation screw
holes with the 2 or 4 plastic caps
included in the instruction bag.
! Place the corrugated plastic sheet,
found on top of the appliance during
the unpacking process, into the base
of the appliance as shown in figure 2
(according to the model, consider
version A, B or C).
A
A
A
A
B
B
B
B
1
3
2
1
3
1
2
A
C
B
2
WARNING:
keep packaging materials
away from children.
In some models this operation
will not be necessary, because
the corrugated plastic sheet
will be already placed on the
bottom of the appliance.

Hoover H-WASH 300 LITE Specifications

General

Style	Front-Loading
Color	White
Washer Capacity	9 kg
Dryer Capactity	-
Max Spin Speed	1400 RPM
Spin Speeds	-
Spin Class	B
Number of Cycles	15+1
Cycle Selections	StainTreat
Wash	Cotton
Options	rinse hold
Hours	Signal On / Off Button
Noise level	79 dB
Temperature Selections	4
Energy Class	D
Annual Energy Consumption	76 kWh
Annual Water Consumption	-
Water Consumption Per Cycle	46 L
Voltage	220-240 V
Frequency	-
Current	-

Weight and Dimensions

Depth	530 mm
Height	850 mm
Width	600 mm
Net Weight	65 kg
