Hoover H-WASH&DRY 500 User Manual

!
6
2. INSTALLATION
l Remove the 2 or 4 transportation
screws (A) on the back and
remove the 2 or 4 flat washers,
rubber bungs and plastic spacer
tubes (B) as illustrated in figure 1.
l If the washing machine is built-
in, unscrew the 3 or 4
transportation screws (A) and
remove the 3 or 4 flat washers,
rubber bungs and plastic spacer
tubes (B).
l During the removal of the screws
occasionally spacer tubes fall
inside the product, these can be
remove by tilting the product forward
and recovering them from the floor
or inside the base of the machine.
l Cover the open transportation screw
holes with the 2 or 4 plastic caps
included in the instruction bag.
l Place the corrugated plastic
sheet, found on top of the
appliance during the unpacking
process*, into the base of the
appliance as shown in figure 2
(according to the model,
consider version A, B or C).
* In some models, the corrugated
plastic sheet is not provided.
A
A
A
A
B
B
B
B
1
3
2
1
3
1
2
A
C
B
2
WARNING:
keep packaging materials
away from children.

Hoover H-WASH&DRY 500 Specifications

General

Load Capacity (Washing)	9 kg
Load Capacity (Drying)	6 kg
Energy Efficiency Class	A
Spin Speed	1400 RPM
Noise Level (Washing)	51 dB
Noise Level (Spinning)	77 dB
Number of Programs	16
Maximum Spin Speed	1400 RPM
Energy Rating	A
Noise Level (Wash)	51 dB
Color	White
Capacity	9 kg (washing), 6 kg (drying)
