6
2. INSTALLATION
! Cut the tube straps, being
careful not to damage the tube
and power cord.
! Unscrew the 2 or 4 screws (A)
on the back and remove the 2
or 4 shims (B) as illustrated in
figure 1.
! Close the 2 or 4 holes using
the plugs included in the
instruction envelope.
! If the washing machine is built-in,
after cutting the hose straps,
unscrew the 3 or 4 screws (A) and
remove the 3 or 4 shims (B).
! In some models, 1 or more
shims will fall inside the machine:
tilt the washing machine forward
to remove them. Close the holes
using the plugs found in the
envelope.
! Place the polionda sheet on
the bottom as shown in figure
2 (according to the model,
consider version A, B or C).
A
A
A
A
B
B
B
B
1
3
2
1
3
1
2
A
C
B
2
WARNING:
keep packaging materials
away from children.
