Push bolts into holes on back
of handle.
4
Slide handle onto cleaner body.
Remove bag door on cleaner
body by pushing down at top
of door and pulling door outward.
Switch (A) above bag door should
be in OFF position.
2
STEP 1 Unpack carton
Remove all parts from carton
and identify each item shown.
Make sure all parts are located
before disposing of packing.
A. Handle section
B. Cleaner body
C. Hose, cleaning tools and wands
D. Handle bolts and nuts packet
(in bag with operating instructions)
A
B
C
D
E
F
Not required for assembly:
E. Optional Paper filter bag
(Cloth bag already installed in cleaner)
F. Extra belt
(One already installed in cleaner)
STEP II Attach handle
1
1
2
2
3
4
3
A
To Next Page
