Align end of hose with projections
(A) over slots (B) in dirt duct.
STEP II Attach hose
1-8
1-11
1-13
1-9
1-10
Place nuts in recessed areas on
front of handle. Hold each nut in
place while tightening each bolt
securely with a Phillips screw driver.
Reposition bag door by fitting tabs
on bottom of door into opening.
Press top of door to snap securely
shut.
Press cord into the 3 notches and
the clip as shown.
Slide hose into (B) and twist hose to
lock it into place.
Lift hose tube cover (C).
NOTE: Hose must be connected as shown for all
operations.
D
B
C
B
E
A
4
Remove bag door on cleaner body
by pushing down at top of door and
pulling door outward.
Switch (A) above bag door should
be in OFF position.
While holding rack in place, slide
handle onto cleaner body.
Make sure tab is inserted fully into
slot.
1-6
1-7
Push bolts into holes on back of
handle.
Position hose over rack and into
hose tube (D) or (E) (depening on
your model).
1-12
1-5
