SPECIFICATIONS
Models Covered WD420 Washer Dryer
WD440 Washer Dryer
Colours P = Polar, G = Graphite, T = Sandstone
Country of Origin Great Britain
Electrical Supply 230 Volts AC @ 50Hz Fuse 13amp
Energy Energy Class: B
Washing Performance Class: A @ 40°C
Energy Consumption 1.02 KWh / Cycle @ 60°C Cotton
Water Consumption Washing Only = 55 Litres @ 60°C Cotton
Wash Load 6 kg Cottons
Washing & Drying Load 5.0 kg + 5.0 kg Cottons
Spin Speed WD420 - 1200 rpm maximum WD440 - 1400 rpm maximum
Control PCB 220/230Volt 50/60Hz Type Merloni EVO 2
Wash Heater 1800 Watts @ 230 volts Resistance 30 Ω approx.
Dryer Heater 1200 Watts @ 230 volts Resistance 43 Ω approx.
Thermistor NTC - Wash Resistance: 20 KΩ @ 20°C
Thermistor NTC - Dryer Resistance: 26 KΩ @ 20°C
Water Supply Hot & Cold Valves - Coil Resistance 3.8 KΩ
Max Pressure = 1 Mpa (10bar)
Minimum Pressure = 0.05 Mpa (0.5bar)
Motor - Wash Universal Series Wound 230V 50Hz AC with tapped field
Motor - Dryer Fan 230 Volt 50 Hz Resistance approx. 45 Ω
Pump 2 Pole Synchronous
220 / 240 Volt 25 Watt, Resistance = 165 Ω
Maximum Head 1.4 metres
Flow rate @ 0.9 metres / 30 Litres per minute
Door Lock P.T.C. Bimetallic - Time Delay approx 2 minutes
Torque Settings Outer Drum = 8Nm
Upper Balance Weight = 18 Nm
Lower Balance Weight = 24 Nm
Heater Box to Drum = 12Nm
Heater Box Top to Bottom = 8Nm
Dimensions Height 850 mm Width 595 mm
Depth 600 mm Weight 66 kg. Packed approx 69 kg
Pins Resistances FHP CESET
5-6 Armature Varies with brush-gear 1.5 Ω ± 8% 1.78 Ω ± 7%
3-4 Full Field 1.26 Ω ± 8% 1.25 Ω ± 7%
3-7 Tapped Field 0.47 Ω ± 10% 0.41 Ω ± 7%
1-2 Tacho 16 Pole (8 pairs) 135 Ω ± 10% 68.7 Ω ± 7%
