INSTALLATION INSTRUCTIONS
UNPACKING THE COOKER
Unpack the components from inside the grill and oven. Check that the following parts are present:
Grill pan and grid Top oven/grill shelf heat shield
Baking dish Pan supports
Main oven shelves (2) Enamelled burner caps (4)
Top oven/grill shelf (1) Literature
Aluminium burner bodies (4)
LEVELLING
Four skid feet are fitted which can be adjusted up or down to level the cooker.
CONVERSION FOR USE ON BUTANE (G30) OR PROPANE (G31)
Each burner requires the injector to be replaced and bypass screws adjusted or replaced as follows:
1. Remove the loose hotplate burner parts.
2. Using a 7mm socket, replace the hotplate injectors as appropriate (see table on previous page).
3. Re-position the loose burner parts.
4. Remove the enamelled baffle at the front of the grill (2 screws).
5. Remove the screw on the right hand side of the burner and gently slide the burner off the injector.
6. Using a 7mm socket, replace the grill injector as appropriate (see table on previous page).
7. Re-assemble the burner and baffle.
8. Inside the top oven, remove the central screw securing the burner retainer. Slide the retainer to the right slightly
and lift away.
9. Lift the burner assembly and place on the floor of the oven to the right of the burner opening.
10. Using a 7mm socket, replace the oven injector as appropriate (see table on previous page).
11. Re-assemble the oven burner and retainer.
12. Replace the main oven injector following the same procedure as for the top oven.
13. From behind the cooker, remove the screws securing the rear panel and swing the left hand side outwards
(viewed from the rear) to gain access to the main oven flame supervision device.
14. Replace the flame supervision device bypass screw.
15. Re-assemble the rear panel.
16. Carefully pull off the control knobs and timer buttons.
17. Remove the 2 screws securing the underside of the control panel. Slide the control panel to the left slightly to
remove.
18. Remove the 6 screws securing the timer mounting panel. Without completely removing it, manoeuvre the timer
mounting panel to gain access to the thermostat bypass screws.
19. Using a narrow flat bladed screwdriver rotate the bypass screws fully clockwise. The main oven thermostat
bypass screw is located on the body of the thermostat below the spindle, the top oven thermostat bypass
screw is located on the body of the thermostat to the right of the spindle and the hotplate tap bypass screws
are located down the centre of the spindle.
20. Re-assemble the control panel parts.
21. Secure the self-adhesive LPG conversion label over the gas details on the data badge.

Hotpoint CH60GCIK Specifications

General

Clock type	Electronic
Control type	Buttons, Rotary
Product type	Freestanding cooker
Product color	Black
Control position	Front
Integrated clock	Yes
Oven size	Large
Noise level	- dB
Cleaning type	Catalytic
Number of ovens	2
Total oven power	- W
Oven power source	Natural gas
Oven gross capacity	77 L
Total oven(s) interior capacity	109 L
Oven 2 gross capacity	32 L
Hob type	Gas
Pan support material	Enameled
Number of cooking zones	4 zone(s)
Energy consumption (conventional)	- kWh

Weight and Dimensions

Width	600 mm
Height	900 mm
