Hotpoint H5T 811I K H User Manual

Use & Care guide
3
Control panel and temperature setting
1. On/off
2. Fridge temperature
indicator
3. Fridge temperature
setting
4. Super indicator light
(rapid freezing)
5. Super button (rapid
freezing)
On/off
The whole product (both fridge and freezer compartments) can be turned on by pressing this button for 2 seconds. The
last set value is indicated on the interface. Press this button to turn off the device. An audible signal will confirm the “off
commutation of the product”.
Fridge temperature indicator
It shows the temperature of the fridge compartment.
Fridge temperature setting
It allows you to change the fridge temperature value, in a cyclical way; it also confirms the selected temperature on the
interface.
Super indicator light (rapid freezing)
lluminates when the SUPER FREEZE button is pressed.
Super button (rapid freezing)
To be used to freeze fresh foods. When it is pressed, the SUPER FREEZE indicator light illuminates (see Start-up and use).
During SUPER function do NOT enable AiR in fridge compartment , can caused too cold temperature. For the best food
conservation MED position is recommended.
Note: Displayed set points correspond to the average temperature throughout the whole refrigerator.
No-frost refrigerator compartment
Refrigerator compartment defrosting is completely automatic.
Droplets of water on the rear wall inside the refrigerator compartment indicate that the automatic defrost phase is in progress.
The No Frost system circulates cold air continuously to collect humidity and prevent ice and frost formation.
The system maintains an optimal humidity level in the compartment, preserving the original quality of the food, preventing the
food from sticking together and making defrosting a thing of the past.
Do not block the aeration cells by placing food or containers in direct contact with the refrigerating back panel.
Close bottles and wrap food tightly.
No-frost freezer compartment
No Frost freezers provide chilled air circulation around the storage areas, and prevent the formation of ice, thereby completely
eliminating the need for defrosting.
Frozen items don’t stick to the walls, labeling stays legible and storage space remains neat and clear.
Compartment 3 in 1 zone
This is the new box which offers maximum flexibility in order to stock your food in an excellent way.
• store meat, fish and delicate food;
• rapid cooling of hot food from 70°C to 3°C and of other fresh foods and leftovers
• low temperature defrosting (it inhibits the proliferation of microorganisms).
You can get the 0°C temperature, in standard conditions, when the fridge compartment temperature is at about 4°C. By
decreasing the fridge temperature you decrease the CHILLER compartment temperature too.

Hotpoint H5T 811I K H Specifications

General

Door hinge	Right
Control type	Touch
Product color	Black
Reversible doors	Yes
Shelves material	Glass
Custom panel-ready	No
Appliance placement	Freestanding
Number of compressors	1
Current	1 A
Connected load	160 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A+++ to D
Annual energy consumption	346 kWh
Star rating	4*
Freezer position	Bottom-placed
Freezing capacity	10 kg/24h
Freezer net capacity	104 L
Freezer number of shelves/baskets	3
Storage time during power failure	17 h
Noise level	40 dB
Climate class	SN-T
Holiday function	-
Total net capacity	338 L
Minimum operating temperature	10 °C
Lamp type	LED
Fridge net capacity	234 L
Fridge door balconies	5
Number of vegetable drawers	2
Cord length	1.6 m

Weight and Dimensions

Depth	678 mm
Width	596 mm
Height	1912 mm
Weight	70000 g
