HP 14-ck0 Series User Manual

Item Component Spare part
number
(1) Display
NOTE: Displays are not spared as whole units. Display subcomponent spare parts are available. For
spare part information, see Display assembly subcomponents on page 19.
Not spared
(2) Top cover/keyboard
NOTE: For a detailed list of country codes, see Top cover with keyboard on page 62.
Keyboard, no backlight, jet black L23239-xx1
Keyboard, no backlight, snow white L23240-xx1
Keyboard, no backlight, ash silver L23241-xx1
Keyboard, backlit, ash silver L23242-xx1
(3) TouchPad module L22586-001
(4) TouchPad button board L23197-001
(5) TouchPad button board bracket L23193-001
(6) Power connector cable (DC-in) L23188-001
(7) System board
NOTE: All system board spare part kits include replacement thermal material.
All system boards use the following part numbers:
xxxxxx-001: Non-Windows operating systems
xxxxxx-601: Windows operating system
For use in models with discrete graphics memory:
●
Intel Core i7-8550U processor with 2 GB of discrete graphics memory L23228-xx1
●
Intel Core i5-8250U processor with 4 GB of discrete graphics memory L23229-xx1
●
Intel Core i5-8250U processor with 2 GB of discrete graphics memory L23227-xx1
●
Intel Core i3-7020U processor with 2 GB of discrete graphics memory L23226-xx1
For use in models with UMA graphics memory:
●
Intel Core i7-8550U processor L23233-xx1
●
Intel Core i5-8250U processor L23232-xx1
●
Intel Core i3-8130U processor L23231-xx1
●
Intel Core i3-7020U processor L23230-xx1
●
Intel Pentium N5000 processor L23236-xx1
●
Intel Celeron N4000 processor L23234-xx1
●
Intel Celeron N4000 processor, models with 64 GB eMMC memory L23235-xx1
(8) USB/card reader/power button board L23196-001
(9) System board hook L23206-001
(10) Speakers (includes cable) L23221-001
16 Chapter 3 Illustrated parts catalog
