B
Technical Specifications
✎
All performance specifications are provided by the component
manufacturers. Performance specifications represent the highest
specification of all HP’s component manufacturers’ typical level
specifications for performance and actual performance may vary
either higher or lower.
1506 Flat Panel Monitor
Display 15.0 inches 38.1 cm
Type TFT LCD
Viewable Image Size 15.0-inch diagonal 38.1 cm
Tilt --5 to 30
o
Maximum Weight 7.0 lbs. 3.20 kg (unpacked)
(Unpacked)
Dimensions (include pedestal)
Height 14.0 inches 355 mm
Depth 8.0 inches 203 mm
Width 13.4 inches 340 mm
Maximum Graphic Resolution 1024 x 768 (60 Hz)
Text Mode 720 x 400
Dot Pitch 0.297 (H) x 0.297 (W) mm
Horizontal Frequency 30 to 63 kHz
User Guide B–1
