Speakers
Table 6-17 Speaker description and part number
Description Spare part number
Speaker Kit L22580-001
Before removing the speakers, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 32).
2. Remove the optical drive (see Optical drive on page 33).
3. Remove the bottom cover (see Bottom cover on page 37).
4. Remove the battery (see Battery on page 40).
5. Remove the system board (see System board on page 61).
Remove the speakers:
1. Remove the antenna cables from the clips in the left speaker (1).
2. Remove the speaker cable from the clips built into the computer (2), and then remove the speakers from
the computer (3).
Reverse this procedure to install the speakers.
Component replacement procedures 65
