HP 1810 Switch Series
Specifications
HP 1810-8G v2 Switch (J9802A) HP 1810-24G v2 Switch (J9803A) HP 1810-48G Switch (J9660A)
Ports
8 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3
Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE
802.3ab Type 1000BASE-T); Duplex:
10BASE-T/100BASE-TX: half or full; 1000BASE-T: full
only
Supports a maximum of 8 autosensing 10/100/1000
ports
24 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3
Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE
802.3ab Type 1000BASE-T); Duplex:
10BASE-T/100BASE-TX: half or full; 1000BASE-T: full
only
2 SFP autosensing 100/1000 ports (IEEE 802.3u Type
100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex:
100BASE-TX: half or full; 1000BASE-T: full only
Supports a maximum of 24 autosensing 10/100/1000
ports plus 2 SFP ports
48 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3
Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE
802.3ab Type 1000BASE-T); Duplex:
10BASE-T/100BASE-TX: half or full; 1000BASE-T: full
only
4 SFP autosensing 100/1000 ports (IEEE 802.3u Type
100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex:
100BASE-TX: half or full; 1000BASE-T: full only
Supports a maximum of 48 autosensing 10/100/1000
ports plus 4 SFP ports
Physical characteristics
7.93(w) x 4.65(d) x 1.73(h) in (20.14 x 11.81 x 4.4 cm)
(1U height)
12.99(w) x 6.81(d) x 1.73(h) in (32.99 x 17.3 x 4.4 cm)
(1U height)
17.4(w) x 9.75(d) x 1.75(h) in (44.2 x 24.77 x 4.45 cm)
(1U height)
Weight
0.84 lb (.38 kg) 2.54 lb (1.15 kg) 6.31 lb (2.86 kg)
Memory and processor
128 MB RAM, 8 MB flash; packet buffer size: 512 KB 128 MB RAM, 8 MB flash; packet buffer size: 512 KB 8 MB flash, 64 MB SDRAM; packet buffer size: 1.5 MB
Mounting
wall, desktop and under table mounting Mounts in an EIA-standard 19 in. telco rack (hardware
included), horizontal surface, wall and under table
mounting
Mounts in an EIA-standard 19 in. telco rack (hardware
included); wall, desktop, tabletop, and under-table
mounting
Performance
100 Mb Latency
< 3.3 µs (64-byte packets) < 3.3 µs (64-byte packets) < 8.4 µs (64-byte packets)
1000 Mb Latency
< 2.3 µs (64-byte packets) < 2.2 µs (64-byte packets) < 3.2 µs (64-byte packets)
Throughput
up to 11.9 million pps up to 38.7 million pps up to 77.4 million pps (64-byte packets)
Switching capacity
16 Gbps 52 Gbps 104 Gbps
MAC address table size
8000 entries 8000 entries 16000 entries
Environment
Operating temperature
0°F to 40°F (-17.8°C to 4.4°C) 0°F to 40°F (-17.8°C to 4.4°C) 32°F to 113°F (0°C to 45°C)
Operating relative humidity
15% to 95% @ 104°F (40°C) 15% to 95% @ 104°F (40°C) 15% to 95% @ 104°F (40°C), noncondensing
Nonoperating/Storage temperature
-40°F to 158°F (-40°C to 70°C) -40°F to 158°F (-40°C to 70°C) -40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage relative humidity
15% to 95% @ 140°F (60°C) 15% to 95% @ 140°F (60°C) 15% to 90% @ 149°F (65°C), noncondensing
Altitude
up to 10,000 ft (3 km) up to 10,000 ft (3 km) up to 10,000 ft (3 km)
Acoustic
Power: 0 dB no fan Power: 0 dB no fan Power: 22 dB single fan
Electrical characteristics
Maximum heat dissipation
204 BTU/hr (215.22 kJ/hr)
Voltage
100-240 VAC 100-127/200-240 VAC 100-127/200-240 VAC
Current
.5 A .4/.3 A 0.9/0.5 A
Maximum power rating
7.2 W 22 W 60 W
Frequency
50/60 Hz 50/60 Hz 50/60 Hz
Notes
Maximum power rating and maximum heat dissipation
are the worst-case theoretical maximum numbers
provided for planning the infrastructure with fully
loaded PoE (if equipped), 100% traffic, all ports plugged
in, and all modules populated.
Maximum power rating and maximum heat dissipation
are the worst-case theoretical maximum numbers
provided for planning the infrastructure with fully
loaded PoE (if equipped), 100% traffic, all ports plugged
in, and all modules populated.
Maximum power rating and maximum heat dissipation
are the worst-case theoretical maximum numbers
provided for planning the infrastructure with fully
loaded PoE (if equipped), 100% traffic, all ports plugged
in, and all modules populated.
Safety
UL 60950-1; IEC 60950; EN 60950 UL 60950-1; IEC 60950; EN 60950 CSA 22.2 No. 60950; EN 60950/IEC 60950; UL 60950
Emissions
EN 55022 Class A; CISPR 22 Class A; VCCI V-3; FCC (CFR
47, Part 15) Subpart B Class A; VCCI V-4
EN 55022 Class A; CISPR 22 Class A; VCCI V-3; FCC (CFR
47, Part 15) Subpart B Class A; VCCI V-4
EN 55022 Class A; CISPR 22 Class A; VCCI V-3; FCC (CFR
47, Part 15) Subpart B Class A; VCCI V-4
Immunity
ESD
IEC 61000-4-2 IEC 61000-4-2 IEC 61000-4-2
Radiated
IEC 61000-4-3 IEC 61000-4-3 IEC 61000-4-3
EFT/Burst
IEC 61000-4-4 IEC 61000-4-4 IEC 61000-4-4
Surge
IEC 61000-4-5 IEC 61000-4-5 IEC 61000-4-5
Conducted
IEC 61000-4-6 IEC 61000-4-6 IEC 61000-4-6
Power frequency magnetic field
IEC 61000-4-8 IEC 61000-4-8 IEC 61000-4-8
Voltage dips and interruptions
IEC 61000-4-11 IEC 61000-4-11 IEC 61000-4-11
Harmonics
EN 61000-3-2 EN 61000-3-2 EN 61000-3-2
Flicker
EN 61000-3-3 EN 61000-3-3 EN 61000-3-3
