Hard drive
Table 5-4 Spare part description and number
Description Spare part number
Hard drive, 1 TB, 5400 rpm 762990-005
Hard drive, 500 GB, 7200 rpm 703267-005
Hard drive, 500 GB, 5400 rpm 778186-005
Hard drive cover L23219-001
Before removing the hard drive, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 26).
2. Remove the bottom cover (see Bottom cover on page 27).
3. Remove the battery (see Battery on page 29).
Remove the hard drive:
1. Disconnect the hard drive cable from the system board ZIF connector (1).
2. Lift the hard drive out of the computer (2).
Component replacement procedures 33
