Setting up the monitor

Installing the monitor stand

CAUTION: Do not touch the surface of the LCD panel. Pressure on the panel may cause non-uniformity of

color or disorientation of the liquid crystals. If this occurs, the screen will not recover to its normal condition.

1. Lay the display head face down on a at surface covered by a clean, dry cloth.

2. Attach the top of the stand arm (1) to the connector (2) on the back of the display panel. The stand arm

will click into place.

3. Slide the base (1) into the bottom of the stand arm until the center holes are aligned. Then tighten the

screw (2) on the underside of the base.

Connecting the cables

NOTE: The monitor ships with select cables. Not all cables shown in this section are included with the

monitor.

1. Place the monitor in a convenient, well-ventilated location near the computer.

Setting up the monitor 5

Questions and Answers:

Need help?

Do you have a question about the HP 27es and is the answer not in the manual?

General

3D	No
Pixel pitch	0.311 x 0.311 mm
Screen shape	Flat
Display diagonal	27 \
Native aspect ratio	16:9
Contrast ratio (dynamic)	1000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
On/off switch	Yes
Tilt angle range	-5 - 25 °
Product color	Black, Silver
Country of origin	China
Market positioning	-
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	29 W
Power consumption (off)	0.14 W
Annual energy consumption	34 kWh
Power consumption (standby)	0.2 W
Power consumption (typical)	24 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	EPEAT Silver, ENERGY STAR
